Function/Arbitrary Waveform Generator for Accurate Waveform Shaping

SIGLENT’s function/arbitrary waveform generator series, including SDG800 to SDG7000A models, cover frequencies from 10 MHz to 1 GHz, with a maximum sampling rate up to 5 GSa/s, demonstrating its strong strength in the field of waveform generation. The instruments not only support up to 512 Mpts arbitrary waveform editing and output, but also have up to 16-bit vertical resolution to ensure accurate reproduction of waveform details. Both single-channel and dual-channel configurations can meet diversified testing needs.

Professional-grade features that break new ground

01

Innovative EasyPulse technology

When traditional DDS method outputs square wave/pulse, if the sampling rate is not integer multiple of the output frequency, it will generate jitter of one sampling period. SIGLENT’s innovative EasyPulse technology overcomes this shortcoming and produces square wave and pulse signals with low jitter.
02

Innovative TrueArb waveform technology

SIGLENT’s innovative TrueArb technology integrates the advantages of DDS to overcome the jitter and distortion produced by DDS technology. TrueArb utilizes a point-by-point output to accurately output signals without missing any details.
02

All-in-one Signal Generator

SIGLENT SDG series set a variety of signal generator functions in one, SDG6000X series and SDG7000A series of function/arbitrary waveform generator has a continuous waveform generation, pulse signal generation, arbitrary waveform generation, IQ signal generation, PRBS code generation and noise signal generation and other functions, and also provides 16-way digital signal output, in certain occasions can replace the RF signal source. In certain occasions, it can replace the RF signal source.
02

Dual Pulse Generator for Easy Power Device Testing

The SDG1000X Plus series has a multi-pulse output function with a minimum 10ns rising/falling edge of the pulse, and the parameters of each pulse can be set individually for easy control of the turn-on/turn-off time. Measurement of switching parameters and dynamic characteristics of power devices can be realized without the need of upper computer software.
02

Simplified Signal Simulation

SigIQPro Signal Generation Software enhances the signal generation capability to a whole new level, supporting Bluetooth, IoT, Custom OFDM, Custom IQ, compatible with customized conversion of various data formats, and supporting the download of waveform files to the SIGLENT signal generator for playback. The SDG7000A series with SigIQPro signal generation software can well integrate simulation, design and test to meet the different needs of customers in all stages of design, R&D, production and test.
02

PRBS code type output to help BER testing

The SDG series is not inferior in high-speed serial channel testing, providing a wide range of code outputs from PRBS3 to PRBS32, and a large output range to meet the needs of most signals. The SDG series can also quickly select preset level logic such as TTL, LVCMOS, and output high-quality differential signals with a single click.

Function/Arbitrary Waveform Generator

SIGLENT’s original EasyPulse technology sets a new performance benchmark for waveform generators, realizing high stability, low jitter, and finely adjustable pulse wave output, which significantly improves the quality and reliability of waveform output. The innovative TrueArb technology, which is a complete transcendence of the traditional DDS technology, ensures precise point-by-point output of arbitrary waveforms without omission or repetition, and eliminates the effects of jitter and distortion. In addition, SDG6000X and SDG7000A also integrate arbitrary waveform generation, IQ signal generation, PRBS code pattern generation and other advanced functions, becoming a model of high-end multifunctional waveform generation equipment, which is widely used in communications, scientific research, education, production testing and other fields, and is the indispensable right-hand man for engineers.
